Couch Roll Broke Chest Pulper for Kraft Paper Mill

The couch roll broke chest pulper plays a key role in the kraft paper making line. When the paper web breaks at the couch roll, the scrap paper falls into this chest. The pulper then breaks this broke paper back into pulp. This allows you to recycle the fiber and feed it back into the system. It reduces waste and keeps your paper production line running without long stops.

Technical Data of Pulper:

Item	Specification
Type	700 spiral mixing propeller
Mechanical Drive	Complete set
Pulp Consistency	2.5—4.0%
Motor Power	30 kW
Main Shaft Speed	90 r/min
Blade Material	Cast iron

This pulper uses a strong spiral propeller to keep the broke pulp moving. It works well at standard broke consistency. The cast iron blades are durable and handle the tough job of repulping. The motor and shaft speed are matched for efficient mixing. These features make it very reliable in the wet area of your paper mill machinery.

We offer this pulper and other paper mill equipment. We supply complete paper production lines for different paper grades. We also provide turnkey paper production line services. If you need a reliable pulper for your kraft paper machine, we can help. Contact us for more information.
