Culture Paper Making Machine Lubrication System

Our company offers an advanced Lubrication System for paper machine projects. This paper making machine component is used in the press section, the front dryer section, and the back dryer section. The Lubrication System lubricates dryer cylinder bearings, Vac cylinder bearings, guide roll bearings, and the reeling machine. It uses a closed circulating oil system to ensure reliable operation. Our Lubrication System includes standard lubrication stations with gear pumps, motors, and control cabinets. The system comes with imported float-type flow meters, group alarms, modular centralized oil supply, and adjustable flow rates. These features make it easy to observe oil supply conditions. As a vital piece of paper mill machinery, our Lubrication System helps you reduce wear, prevent overheating, and extend the service life of your paper production equipment.

In practice, lubrication systems can suffer from oil temperature swings, pressure instability, low oil levels, filter blockage, and pump failure. These problems can lead to bearing damage and unplanned downtime on your paper making line. Our Lubrication System addresses these issues with a range of smart features. The oil tank of our Lubrication System has a partition wall that separates return oil from clean oil. This design improves the separation of air and water from the oil. Return oil from lubrication points flows through a return oil filter before entering the main oil tank. This return oil filter can be cleaned during operation. The oil tank is equipped with a thermal cycle, high and low level switches, an electric heater, temperature sensors, and an air filter. For pressure control, the Lubrication System uses oil pumps with a main pump and a standby pump. You can select and start the main pump from the paper machine control system. If the main pump stops, the standby pump starts automatically. The oil filter of our Lubrication System has filter elements that can be replaced while the machine is running. A differential pressure display shows when replacement is needed. This display also triggers an alarm in the paper machine control center. A safety valve is installed on the oil inlet pipe of the filter. The oil cooler of our Lubrication System is a plate heat exchanger. A temperature control valve is installed in the cooling water outlet pipe. The flow meter panel distributes oil to each lubrication point. Each oil inlet pipe on the control panel has a shut-off valve. The control panel has an oil leak tray. Flexible hoses are used for movable lubrication points. Quick-change couplings are used at points that need frequent maintenance, such as the dryer fabric change area.

In addition to our Lubrication System, we can supply complete paper production lines for many other paper grades. We offer paper making lines for cultural paper, newsprint, writing paper, linerboard, corrugated paper, and specialty paper. Our range of paper mill machinery includes pulpers, refiners, screens, cleaners, headboxes, paper forming machines, press sections, drying sections, calenders, and reeling machines. We also provide turnkey paper production line services, handling everything from design to installation. Contact us to find out how our Lubrication System and other paper processing line equipment can improve your operation.

For more details, please email us at: leizhanworld@gmail.com
