Corrugated Paper Project Hydraulic System

Hydraulic system is a crucial part of the paper making line. It provides the power to control the press section and ensures steady pressure for the paper web. A reliable Hydraulic system is necessary because it directly affects the dewatering process and the final paper quality. It keeps your paper mill machinery running safely and smoothly without sudden stops. Without a good Hydraulic system, the paper production line cannot maintain the high pressure needed for quality paper.

Our Hydraulic system comes as one complete set for the press section, while the sizing machine uses a separate unit. It includes hydraulic cylinders, a hydraulic station, piping, motors, and variable pumps with one standby. It also has a circulation oil pump, filters, proportional relief valves, and pressure reducing valves. An accumulator, directional valves, speed control valves, check valves, and pressure gauges are included. The system has cooling and heating devices along with a junction box. It links with the DCS and MCS systems and reserves an Ethernet interface. It features shock protection. The cooler uses a stainless steel plate type. We use stainless steel for the pumps, valves, pipes, and fittings. The pipe supports use stainless steel, and we use bite-type hydraulic fittings with O-rings. The system pressure uses a proportional relief valve for remote control with closed-loop control. Pressure on both sides of the press points is remotely controlled by proportional pressure valves.

The return oil system has a low-pressure filter, and the supply system has a high-pressure filter. An air filter is on the tank. All filters have differential pressure alarms. Oil temperature is kept below the limit using sensors and cooling or heating devices. Pressure sensors are on the main system and each press point to send alarms if pressure changes. A low oil level sensor sends an alarm if oil is low. An accumulator prevents hydraulic shocks, and there is an emergency stop pressure relief control. We offer this high-quality Hydraulic system and other paper mill machinery. We supply complete paper production lines for different paper grades. We also provide turnkey paper production line services. If you need a reliable Hydraulic system for your paper making machine, we can help. Contact us for more information.
